1, a good anti-metal properties can be achieved in metal performance long-range reader with anti-metal, high temperature, water, acid and alkali resistance, impact resistance and other characteristics
2, multi-tag identification, identification of high sensitivity, fast, with co ball
3 unique identification code, mainly for warehouse pallets, equipment inspection, asset tags and other metal application support.
|
Basic Parameters |
|
|
Types |
UHF passive RFID tags |
|
Working Frequency |
860-960MHz |
|
Protocol |
ISO / IEC 18000-6C EPC Class1 Gen2 |
|
Physical Parameters |
|
|
Size |
125 * 21.5 * 12.5mm or customized |
|
Packaging Materials |
ABS+ Gelatin sponge |
|
Antenna |
Aluminum etching antenna |
|
Craft |
Silk screen print, Inkjet print, Encoding |
|
Performance Parameters |
|
|
Chip |
Alien H3, impinjM4D / M4E / M4QT / M5 |
|
Storage |
Related to the chip |
|
Operating mode |
read and write |
|
Data storage time |
> 10 years |
|
Write Endurance |
100,000 times |
|
Reading Distance |
0-10m (the reading range is related to the working condition and reader) |
|
Environmental Parameters |
|
|
operating temperature |
(-25 ℃ ~ + 55 ℃) |
|
Storage temperature |
(-35 ℃ ~ + 75 ℃) |
|
Typical applications |
|
|
Applications |
Warehouse management, Asset management |
|
Packaging |
|
|
Packaging Information |
10pcs / bag, 500 pcs/ Box |
