This is PCB UHF rfid anti metal tag equipped with ucode8/H9 chip which provides industry-leading performance and up to a 4.7 meters reading range. Size 22x8mm with a thickness of 3.0mm. This NXP UHF rfid tags is complies with ISO18000-6C standard and work at frequency of (EU)865~868MHz / (US)902～928MHz. At present, Rayfine IOT supply UHF anti metal RFID tag with more than 100 existing moulds which are widely used for tracking medical devices, surgical instruments tray, heavy industry, oil & gas & mining, automatic production line, logistic tray tracking, warehouse storage rack, container tracking and so on.
RT-PCB4010 is a UHF rfid anti metal tag equipped with ucode8/H9 chip which provides industry-leading performance and up to a 4.7 meters reading range. Size 22x8mm with a thickness of 3.0mm. This NXP UHF rfid tags is complies with ISO18000-6C standard and work at frequency of (EU)865~868MHz / (US)902～928MHz. At present, Rayfine IOT supply UHF anti metal RFID tag with more than 100 existing moulds which are widely used for tracking medical devices, surgical instruments tray, heavy industry, oil & gas & mining, automatic production line, logistic tray tracking, warehouse storage rack, container tracking and so on.
|
Size |
40x10mm, (Hole: D2mm*2) |
|
Thickness |
3.0mm without IC bump, 3.8mm with IC bump |
|
Material |
FR4(PCB) |
|
Colour |
Black ( White,red,green,blue..) |
|
Mounting Methods |
Adhesive, Screw |
|
Weight |
4g |
|
Air Interface Protocol - Standard |
EPC global Gen2，ISO/IEC 18000-6C |
|
Operating Frequency |
(EU)865~868MHz / (US)902～928MHz |
|
IC Type |
UCODE 8 |
|
Memory |
EPC 96bits (Up to 480bits) , USER 512bits, TID64bits |
|
Write Cycles |
100,000 Times |
|
Functionality |
Read/write |
|
Data Retention |
50 Year |
|
Applicable Surface |
Metal Surfaces |
|
Read Range(fixed reader) |
Up to 4.5m - (US) 902-928 MHz, on metal |
|
Up to 4.7m - (EU) 865-869 MHz, on metal |
|
|
Read Range(handheld reader) |
Up to 2.6m - (US) 902-928 MHz, on metal |
|
Up to 3.0m - (EU) 865-869 MHz, on metal |
|
|
Warranty |
1 year |
|
IP Rating: |
IP68 |
|
Storage Temperature |
-40°C to +150°C |
|
Operation Temperature |
-40°C to +100°C |
|
Certifications |
Reach Approved, RoHS Approved, CE Approved |
